PD105R-823K
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active ONE SURFACE fixed air core inductor -55C~125C 1kHz 250mOhm Max 82muH
PDF
/
Inventory: 9483
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series PD105R
Size / Dimension 0.386Lx0.346W 9.80mmx8.79mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 9.2mm
Construction Rectangular
Current Rating 1A
Inductance 82μH
Test Frequency 1kHz
DC Resistance (DCR) 250mOhm Max
Max DC Current 1A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 3935
Dimensions
Height 5.4mm
Height Seated (Max) 0.213 5.40mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
