PD104R-334K

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active ONE SURFACE fixed air core inductor -55C~125C 1kHz 1.1Ohm Max 330muH
PDF
/
Inventory: 3469
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.157 4.00mm
Height 4mm

Technical

Case/Size Code 3935
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 420mA
DC Resistance (DCR) 1.1Ohm Max
Test Frequency 1kHz
Inductance 330μH
Current Rating 420mA
Construction Rectangular
Depth 9.2mm
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension 0.386Lx0.346W 9.80mmx8.79mm
Series PD104R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
