P160R-183HS

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND Fixed Inductor -55C~125C 100kHz 1Ohm Max 18muH
PDF
/
Inventory: 7303
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2010
Series P160R
Size / Dimension 0.155Lx0.125W 3.94mmx3.18mm
Tolerance ±3%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Depth 3.18mm
Construction Chip
Current Rating 350mA
Inductance 18μH
Test Frequency 100kHz
DC Resistance (DCR) 1Ohm Max
Max DC Current 350mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 358mA
Case/Size Code 1512

Dimensions

Height 2.54mm
Height Seated (Max) 0.100 2.54mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
