P1330R-123K
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active Lead Free fixed air core inductor -55C~125C 1kHz 252mOhm Max 12muH
PDF
/
Inventory: 8688
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2002
Series P1330R
Size / Dimension 0.313Lx0.115W 7.94mmx2.92mm
Tolerance ±10%
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 3.18mm
Construction Rectangular
Current Rating 912mA
Inductance 12μH
Test Frequency 1kHz
DC Resistance (DCR) 252mOhm Max
Max DC Current 912mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 516mA
Case/Size Code 3313
Dimensions
Height 3.68mm
Height Seated (Max) 0.145 3.68mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
