P1330R-103K
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
P1330R Nonstandard 0.313Lx0.115W 7.94mmx2.92mm 10muH
PDF
/
Buying Options
Total Price: USD $2.58
Unit Price: USD $2.5784
≥1 USD $2.5784
≥10 USD $2.15688
≥100 USD $1.969088
≥500 USD $1.68784
≥1000 USD $1.547216
≥3000 USD $1.500294
Inventory: 1093
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2003
Series P1330R
Size / Dimension 0.313Lx0.115W 7.94mmx2.92mm
Tolerance ±10%
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 3.18mm
Construction Rectangular
Current Rating 946mA
Inductance 10μH
Test Frequency 1kHz
DC Resistance (DCR) 216mOhm Max
Max DC Current 946mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 564mA
Case/Size Code 3313
Dimensions
Height 3.68mm
Height Seated (Max) 0.145 3.68mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
