P1330-182G

API Delevan Inc.
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active WRAPAROUND fixed air core inductor -55C~125C 1kHz 48mOhm Max 1.8muH
PDF
/
Inventory: 8140
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series P1330
Size / Dimension 0.325Lx0.125W 8.26mmx3.18mm
Tolerance ±2%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding NO
Number of Functions 1
Depth 3.18mm
Current Rating 1.95A
Inductance 1.8μH
Test Frequency 1kHz
DC Resistance (DCR) 48mOhm Max
Max DC Current 1.95A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 1.18A
Case/Size Code 3111

Dimensions

Height 3.68mm
Height Seated (Max) 0.145 3.68mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
