MIL8532-31L
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active WRAPAROUND Fixed Inductor -55C~130C 1kHz 650mOhm Max 330muH
PDF
/
Inventory: 5866
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.286 7.26mm
Height 7.26mm
Technical
Current - Saturation 350mA
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 740mA
DC Resistance (DCR) 650mOhm Max
Test Frequency 1kHz
Inductance 330μH
Reference Standard MIL-PRF-27/370
Current Rating 740mA
Construction Rectangular
Depth 8.38mm
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±15%
Size / Dimension 0.860Lx0.320W 21.84mmx8.12mm
Series MIL8532
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~130°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 46 Weeks
