MIL1812-121K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active WRAPAROUND Fixed Inductor -55C~125C 600MHz 300mOhm Max 120nH
PDF
/
Inventory: 7550
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Iron
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2017
Series MIL1812
Size / Dimension 0.189Lx0.134W 4.80mmx3.40mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 3.4mm
Construction Rectangular
Current Rating 818mA
Reference Standard M83446/39
Inductance 120nH
Test Frequency 25MHz
DC Resistance (DCR) 300mOhm Max
Max DC Current 818mA
Frequency - Self Resonant 600MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 30 @ 25MHz
Quality Factor-Min (at L-nom) 30
Inductor Type GENERAL PURPOSE INDUCTOR
Dimensions
Height 3.4mm
Height Seated (Max) 0.134 3.40mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
