ER1840-34KM
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active WIRE Fixed Inductor -55C~105C 30MHz 1.2Ohm Max 15muH
PDF
/
Inventory: 8240
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Weight 949.99252mg
Material - Core Iron
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2012
Series ER1840
Size / Dimension 0.187Diax0.437L 4.75mmx11.10mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding NO
Number of Functions 1
Current Rating 310mA
Lead Length 36.58mm
Lead Diameter 0.635 mm
Inductance 15μH
Test Frequency 2.5MHz
DC Resistance (DCR) 1.2Ohm Max
Max DC Current 310mA
Frequency - Self Resonant 30MHz
Inductor Application RF INDUCTOR
Q @ Freq 55 @ 2.5MHz
Quality Factor-Min (at L-nom) 55
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
