ER1840-06KP
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active WIRE Fixed Inductor -55C~125C 300MHz 85mOhm Max 470nH
PDF
/
Inventory: 1558
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Quality Factor-Min (at L-nom) 50
Q @ Freq 50 @ 25MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 300MHz
Max DC Current 1.7A
DC Resistance (DCR) 85mOhm Max
Test Frequency 25MHz
Inductance 470nH
Lead Diameter 0.635 mm
Lead Length 36.58mm
Current Rating 1.7A
Number of Functions 1
Shielding NO
Packing Method TR, 14 INCH
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn63Pb37)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Size / Dimension 0.187Diax0.437L 4.75mmx11.10mm
Series ER1840
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Phenolic
Weight 949.99252mg
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
