ER1025-32KP
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active WIRE fixed air core inductor -55C~105C 90MHz 850mOhm Max 3.3muH
PDF
/
Inventory: 3183
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Weight 299.994654mg
Material - Core Iron
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2012
Series ER1025
Size / Dimension 0.095Diax0.250L 2.41mmx6.35mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding NO
Number of Functions 1
Current Rating 270mA
Lead Length 36.53mm
Lead Diameter 0.51 mm
Inductance 3.3μH
Test Frequency 7.9MHz
DC Resistance (DCR) 850mOhm Max
Max DC Current 270mA
Frequency - Self Resonant 90MHz
Inductor Application RF INDUCTOR
Q @ Freq 45 @ 7.9MHz
Quality Factor-Min (at L-nom) 45
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
