5500-562K

API Delevan Inc.
RoHS
/
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Active 2011 Tape & Reel (TR) Fixed Inductor -55C~130C 1kHz 11Ohm Max 5.6muH
PDF
/
Inventory: 5890
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Width 12.954mm
Length 27.432mm
Height Seated (Max) 0.520 13.21mm
Height 13.21mm

Technical

Current - Saturation 7.61A
Inductance Frequency - Test 1kHz
Max DC Current 9.5A
DC Resistance (DCR) 11Ohm Max
Test Frequency 1kHz
Inductance 5.6μH
Current Rating 9.5A
Depth 12.96mm
Shielding Unshielded
Current Rating (Amps) 9.5A
Min Operating Temperature -55°C
Max Operating Temperature 130°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 1.080Lx0.510W 27.44mmx12.96mm
Series 5500
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~130°C

Physical

Material - Core Ferrite
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 5 Weeks
