5022-682H
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
5022 Nonstandard 0.520Lx0.250W 13.21mmx6.35mm 6.8muH
PDF
/
Inventory: 3854
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 45 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Iron
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2007
Series 5022
Size / Dimension 0.520Lx0.250W 13.21mmx6.35mm
Tolerance ±3%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 6.35mm
Construction Epoxy Molded
Current Rating 820mA
Inductance 6.8μH
Test Frequency 7.9MHz
DC Resistance (DCR) 500mOhm Max
Max DC Current 820mA
Frequency - Self Resonant 55MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 50 @ 7.9MHz
Quality Factor-Min (at L-nom) 50
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 50
Dimensions
Height 5.84mm
Height Seated (Max) 0.230 5.80mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
