4922R-01L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
4922R Nonstandard 0.505Lx0.240W 12.82mmx6.09mm 1muH
PDF
/
Buying Options
Total Price: USD $3.77
Unit Price: USD $3.7664
≥1 USD $3.7664
≥10 USD $3.15216
≥100 USD $2.877952
≥500 USD $2.466992
≥1000 USD $2.261336
≥3000 USD $2.192854
Inventory: 642
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.230 5.84mm
Height 5.842mm
Technical
Case/Size Code 5225
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 5.5A
DC Resistance (DCR) 13mOhm Max
Test Frequency 1kHz
Inductance 1μH
Current Rating 5.5A
Construction Rectangular
Depth 6.35mm
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±15%
Size / Dimension 0.505Lx0.240W 12.82mmx6.09mm
Series 4922R
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 45 Weeks
