4922-02K
RoHS
/
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Wirewound Active WRAPAROUND Fixed Inductor -55C~125C 1kHz 18mOhm Max 1.2muH
PDF
/
Inventory: 8039
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 45 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD
Terminal Shape WRAPAROUND
Number of Pins 2
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2015
Series 4922
Size / Dimension 0.520Lx0.250W 13.21mmx6.35mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Depth 6.35mm
Construction Epoxy Molded
Current Rating 4.69A
Inductance 1.2μH
Test Frequency 1kHz
DC Resistance (DCR) 18mOhm Max
Max DC Current 4.69A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Dimensions
Height 5.84mm
Height Seated (Max) 0.230 5.84mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
