4302R-332H
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND Fixed Inductor -55C~125C 40MHz 1.85Ohm Max 3.3muH
PDF
/
Inventory: 1341
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.095 2.41mm
Height 2.41mm
Technical
Case/Size Code 1110
Q Factor 30
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 30
Q @ Freq 30 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 40MHz
Max DC Current 285mA
DC Resistance (DCR) 1.85Ohm Max
Test Frequency 7.9MHz
Inductance 3.3μH
Case Code (Imperial) 1008
Case Code (Metric) 2520
Current Rating 285mA
Construction Rectangular
Depth 2.66mm
Number of Functions 1
Shielding Unshielded
Packing Method TR, 7/13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±3%
Size / Dimension 0.115Lx0.105W 2.92mmx2.66mm
Series 4302R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron Powder
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 45 Weeks
