4232-222J
RoHS
/
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Wirewound Active WRAPAROUND Fixed Inductor -55C~125C 55MHz 1.2Ohm Max 2.2muH
PDF
/
Inventory: 8696
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Mount Surface Mount
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Terminal Shape WRAPAROUND
Package / Case 2-SMD
Supply Chain
Factory Lead Time 50 Weeks
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.101 2.57mm
Height 2.57mm
Technical
Case/Size Code 1210
Q Factor 30
Quality Factor-Min (at L-nom) 30
Q @ Freq 30 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 55MHz
Max DC Current 416mA
DC Resistance (DCR) 1.2Ohm Max
Test Frequency 7.9MHz
Inductance 2.2μH
Current Rating 416mA
Depth 2.67mm
Number of Functions 1
Shielding NO
Packing Method TR, 7/13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn/Pb)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±5%
Size / Dimension 0.138Lx0.105W 3.51mmx2.67mm
Series 4232
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
