2890R-14H
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Molded Active WIRE Fixed Inductor -55C~125C 80MHz 745mOhm Max 5.6muH
PDF
/
Inventory: 9490
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Material - Core Phenolic
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series 2890R
Size / Dimension 0.280Diax0.900L 7.11mmx22.86mm
Tolerance ±3%
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin/Copper (Sn99.3Cu0.7)
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding NO
Number of Functions 1
Current Rating 760mA
Lead Length 36.58mm
Inductance 5.6μH
Test Frequency 7.9MHz
DC Resistance (DCR) 745mOhm Max
Max DC Current 760mA
Frequency - Self Resonant 80MHz
Inductor Application RF INDUCTOR
Q @ Freq 60 @ 7.9MHz
Quality Factor-Min (at L-nom) 60
Q Factor 60
Dimensions
Diameter 7.11mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
