2890R-02H

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Molded Active WIRE Fixed Inductor -55C~125C 160MHz 90mOhm Max 1.5muH
PDF
/
Inventory: 5012
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter 7.11mm

Technical

Q Factor 60
Quality Factor-Min (at L-nom) 60
Q @ Freq 60 @ 7.9MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 160MHz
Max DC Current 2.19A
DC Resistance (DCR) 90mOhm Max
Test Frequency 7.9MHz
Inductance 1.5μH
Lead Length 36.58mm
Current Rating 2.19A
Number of Functions 1
Shielding NO
Packing Method TR, 14 INCH
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn99.3Cu0.7)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±3%
Size / Dimension 0.280Diax0.900L 7.11mmx22.86mm
Series 2890R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Shape/Size Description TUBULAR PACKAGE
Material - Core Phenolic
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 15 Weeks
