2510R-36F

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND Fixed Inductor -55C~105C 90MHz 1.35Ohm Max 3.3muH
PDF
/
Inventory: 6534
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.110 2.79mm
Height 2.79mm

Technical

Q Factor 35
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 35
Q @ Freq 35 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 90MHz
Max DC Current 187mA
DC Resistance (DCR) 1.35Ohm Max
Test Frequency 7.9MHz
Inductance 3.3μH
Current Rating 187mA
Depth 2.67mm
Number of Functions 1
Shielding NO
Packing Method TR, 7/13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±1%
Size / Dimension 0.255Lx0.105W 6.48mmx2.67mm
Series 2510R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
