2500R-24F

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Molded Active WIRE Fixed Inductor -55C~105C 3.1MHz 15.1Ohm Max 820muH
PDF
/
Inventory: 1452
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Material - Core Iron
Shape/Size Description TUBULAR PACKAGE

Technical

Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2010
Series 2500R
Size / Dimension 0.240Diax0.740L 6.10mmx18.80mm
Tolerance ±1%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Current Rating 92mA
Reference Standard MS90539
Lead Length 36.58mm
Inductance 820μH
Test Frequency 790kHz
DC Resistance (DCR) 15.1Ohm Max
Max DC Current 92mA
Frequency - Self Resonant 3.1MHz
Inductor Application RF INDUCTOR
Q @ Freq 60 @ 790kHz
Quality Factor-Min (at L-nom) 60
Q Factor 60

Dimensions

Diameter 4.83mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
