2256-08K
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active WIRE Fixed Inductor -55C~125C 1kHz 42mOhm Max 3.9muH
PDF
/
Inventory: 2802
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series 2256
Size / Dimension 0.225Diax0.570L 5.72mmx14.48mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding Unshielded
Number of Functions 1
Construction Tubular
Current Rating 3.07A
Lead Length 31.75mm
Lead Diameter 0.76 mm
Inductance 3.9μH
Test Frequency 1kHz
DC Resistance (DCR) 42mOhm Max
Max DC Current 3.07A
Inductor Application POWER INDUCTOR
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
