1812-124G
RoHS
/
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Fixed Inductors 120uH 2% 8ohm Unshielded SMT Induc
PDF
/
Inventory: 5373
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.190 4.83mm
Height 3.4mm
Technical
Q Factor 40
Inductor Type GENERAL PURPOSE INDUCTOR
Q @ Freq 40 @ 790kHz
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 6MHz
Max DC Current 158mA
DC Resistance (DCR) 8Ohm Max
Test Frequency 790kHz
Inductance 120μH
Case Code (Metric) 4532
Current Rating 158mA
Construction Rectangular
Depth 3.4mm
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±2%
Size / Dimension 0.126Lx0.126W 3.20mmx3.20mm
Series 1812
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
