1812-104K

API Delevan Inc.
RoHS
/
Package 1812 (4532 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description 1812 1812 (4532Metric) 0.177Lx0.126W 4.50mmx3.20mm 100muH
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.751417
≥1 USD $2.751417
≥10 USD $2.595677
≥100 USD $2.448752
≥500 USD $2.310145
≥1000 USD $2.17938
Inventory: 1141
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1812 (4532 Metric)
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2002
Series 1812
Size / Dimension 0.177Lx0.126W 4.50mmx3.20mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
Packing Method TR, 7/13 Inch
Shielding NO
Number of Functions 1
Depth 3.4mm
Current Rating 158mA
Case Code (Metric) 4532
Inductance 100μH
Test Frequency 2.5MHz
DC Resistance (DCR) 8Ohm Max
Max DC Current 158mA
Frequency - Self Resonant 8MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 50 @ 2.5MHz
Quality Factor-Min (at L-nom) 50
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 50
Case/Size Code 1913

Dimensions

Height 3.4mm
Height Seated (Max) 0.134 3.40mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
