1641R-124K

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description 1641R Axial 0.162Diax0.410L 4.11mmx10.41mm 120muH
PDF
/
Buying Options
Total Price: USD $4.81
Unit Price: USD $4.81379
≥1 USD $4.81379
≥10 USD $4.541316
≥100 USD $4.284255
≥500 USD $4.041752
≥1000 USD $3.812977
Inventory: 5777
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter 254μm

Technical

Special Feature Q IS MEASURED AT: 0.79 MHZ
Q Factor 55
Current - Saturation 95mA
Quality Factor-Min (at L-nom) 55
Q @ Freq 55 @ 790kHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 9.7MHz
Max DC Current 153mA
DC Resistance (DCR) 3.6Ohm Max
Test Frequency 790kHz
Inductance 120μH
Lead Length 36.6mm
Reference Standard MS75089
Current Rating 153mA
Construction Tubular
Number of Functions 1
Shielding YES
Packing Method TR, 14 INCH
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Last Time Buy
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Series 1641R
Published 2005
Packaging Bulk
Operating Temperature -55°C~105°C

Physical

Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Weight 1g
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount PCB, Through Hole
