160-150KS

API Delevan Inc.
RoHS
/
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active 2012 fixed air core inductor -55C~125C 900MHz 60mOhm Max 15nH
PDF
/
Inventory: 7102
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD
Number of Pins 2
Material - Core Phenolic

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2012
Series 160
Size / Dimension 0.150Lx0.120W 3.81mmx3.05mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding Unshielded
Depth 3.18mm
Construction Chip
Current Rating 1.45A
Inductance 15nH
Test Frequency 150MHz
DC Resistance (DCR) 60mOhm Max
Max DC Current 1.45A
Frequency - Self Resonant 900MHz
Q @ Freq 48 @ 150MHz
Quality Factor-Min (at L-nom) 48
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 48

Dimensions

Height 2.03mm
Height Seated (Max) 0.080 2.03mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
