1537-728K
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Active Tape & Reel (TR) Ferrite fixed air core inductor 23MHz 2.4Ohm 47muH ±10%
PDF
/
Inventory: 7591
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 9.525mm
Technical
Current - Saturation 55mA
Inductance Frequency - Test 2.3MHz
Q @ Freq 55 @ 2.5MHz
Frequency - Self Resonant 23MHz
DC Resistance (DCR) 2.4Ohm
Test Frequency 2.3MHz
Inductance 47μH
Current Rating 245mA
Shielding Shielded
Current Rating (Amps) 245mA
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±10%
Size / Dimension 0.156Diax0.375L 3.96mmx9.53mm
Series 1537-7
Packaging Tape & Reel (TR)
Physical
Material - Core Ferrite
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
