1210R-472G
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active J BEND Fixed Inductor -55C~125C 45MHz 1.5Ohm Max 4.7muH
PDF
/
Inventory: 7305
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.101 2.57mm
Height 2.5654mm
Technical
Q Factor 30
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 30
Q @ Freq 30 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 45MHz
Max DC Current 352mA
DC Resistance (DCR) 1.5Ohm Max
Test Frequency 7.9MHz
Inductance 4.7μH
Current Rating 352mA
Depth 2.67mm
Number of Functions 1
Shielding NO
Packing Method TR, 7 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±2%
Size / Dimension 0.128Lx0.095W 3.26mmx2.41mm
Series 1210R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape J BEND
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount
