106-562K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
106 Nonstandard 0.155Lx0.110W 3.94mmx2.79mm 5.6muH
PDF
/
Buying Options
Total Price: USD $76.33
Unit Price: USD $76.32938
≥1 USD $76.32938
≥200 USD $30.456654
≥500 USD $29.437844
≥1000 USD $28.935003
Inventory: 6596
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.075 1.91mm
Height 1.91mm
Technical
Case/Size Code 1611
Q Factor 41
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 41
Q @ Freq 41 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 45MHz
Max DC Current 185mA
DC Resistance (DCR) 2.6Ohm Max
Test Frequency 7.9MHz
Inductance 5.6μH
Current Rating 185mA
Construction Rectangular
Depth 2.79mm
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Terminal Finish Gold (Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code no
JESD-609 Code e4
Tolerance ±10%
Size / Dimension 0.155Lx0.110W 3.94mmx2.79mm
Series 106
Published 2002
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
