1008-470K

API Delevan Inc.
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description 1008 Nonstandard 0.105Lx0.095W 2.66mmx2.41mm 47nH
PDF
/
Inventory: 9326
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.095 2.41mm
Height 2.41mm

Technical

Q Factor 30
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 30
Q @ Freq 30 @ 50MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 1.22GHz
Max DC Current 1.008A
DC Resistance (DCR) 120mOhm Max
Test Frequency 50MHz
Inductance 47nH
Case Code (Metric) 2520
Current Rating 1.008A
Construction Rectangular
Depth 2.66mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Size / Dimension 0.105Lx0.095W 2.66mmx2.41mm
Series 1008
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Phenolic
Terminal Shape J BEND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 45 Weeks
