100-222J
RoHS
/
Package Nonstandard, 2 Lead
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active Radial fixed air core inductor -55C~105C 80MHz 1.7Ohm Max 2.2muH
PDF
/
Inventory: 2241
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.065 1.65mm
Height 1.65mm
Technical
Case/Size Code 1010
Q Factor 35
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 35
Lead/Base Style Radial
Q @ Freq 35 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 80MHz
Max DC Current 96mA
DC Resistance (DCR) 1.7Ohm Max
Test Frequency 7.9MHz
Inductance 2.2μH
Lead Length 5.33mm
Lead Pitch 2.41mm
Reference Standard MS21367
Current Rating 96mA
Construction Epoxy Encapsulated
Depth 2.79mm
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn60Pb40)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±5%
Size / Dimension 0.100Lx0.100W 2.54mmx2.54mm
Series 100
Published 2010
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron
Terminal Shape WRAPAROUND
Package / Case Nonstandard, 2 Lead
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Factory Lead Time 15 Weeks
