0819-94H
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Molded Active WIRE Fixed Inductor -55C~105C 3.9MHz 72Ohm Max 820muH
PDF
/
Inventory: 8830
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Diameter 1.98mm
Technical
Q Factor 35
Quality Factor-Min (at L-nom) 35
Q @ Freq 35 @ 790kHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 3.9MHz
Max DC Current 25.5mA
DC Resistance (DCR) 72Ohm Max
Test Frequency 790kHz
Inductance 820μH
Lead Length 38.1mm
Current Rating 25.5mA
Construction Cylindrical
Number of Functions 1
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn/Pb)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±3%
Size / Dimension 0.078Diax0.200L 1.98mmx5.08mm
Series 819
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
