160-122JS

API Delevan
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description Fixed Inductors 1.2uH 5% .42ohm Chip SMT Inductor
PDF
/
Inventory: 3063
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Packaging Bulk
Tolerance 5%
JESD-609 Code e0
Pbfree Code no
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
HTS Code 8504.50.80.00
Shielding Unshielded
Number of Functions 1
Depth 3.18mm
Construction Chip
Current Rating 545mA
Inductance 1.2 μH
Test Frequency 7.9MHz
Max DC Current 545mA
Frequency - Self Resonant 130MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 36
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 36
Case/Size Code 1613
DC Resistance (DCR) - Parallel 420mOhm
Inductance-Nom (L) 1.2 μH

Dimensions

Height 2.03mm
Height Seated (Max) 2.032mm
Length 3.81mm
Width 3.18mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
