100-221M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Active Radial Fixed Inductor 105C 250MHz 210mOhm 220nH
PDF
/
Inventory: 3263
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 2.54mm
Length 2.54mm
Height Seated (Max) 1.651mm
Height 1.65mm
Technical
Inductance-Nom (L) 0.22 μH
DC Resistance (DCR) - Parallel 210mOhm
Q Factor 40
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 40
Lead/Base Style Radial
Inductor Application RF INDUCTOR
Frequency - Self Resonant 250MHz
Max DC Current 274mA
Test Frequency 25MHz
Inductance 220 nH
Lead Length 5.33mm
Lead Pitch 2.41mm
Current Rating 274mA
Construction Rectangular
Depth 2.79mm
Number of Functions 1
Shielding Unshielded
HTS Code 8504.50.80.00
Min Operating Temperature -55°C
Max Operating Temperature 105°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance 20%
Published 2002
Packaging Bulk
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape FLAT
Package / Case Nonstandard
Mount Free Hanging
