0805R-18NJ

API Delevan
RoHS
/
Package SMD/SMT
Category Inductors, Coils, Chokes / Fixed Inductors
Description RoHS Compliant Tape & Reel Ceramic Surface Mount Fixed Inductor 125C 3.3GHz 200mOhm 18nH
PDF
/
Inventory: 5635
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case SMD/SMT
Material - Core Ceramic

Technical

Packaging Tape & Reel
Tolerance 5%
Pbfree Code yes
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Shielding Unshielded
Depth 1.73mm
Current Rating 600mA
Inductance 18 nH
Test Frequency 250MHz
Max DC Current 600mA
Frequency - Self Resonant 3.3GHz
Q Factor 50
DC Resistance (DCR) - Parallel 200mOhm

Dimensions

Height 1.52mm
Height Seated (Max) 1.524mm
Length 2.286mm
Width 1.73mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
