0603R-1N6K
RoHS
/
Package 0603
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Fixed Inductors .0016uH 10% .04ohm WW SMT 700mA
PDF
/
Inventory: 3623
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.14mm
Length 1.8034mm
Height Seated (Max) 1.016mm
Height 1.02mm
Technical
Inductance-Nom (L) 0.0016 μH
DC Resistance (DCR) - Parallel 40mOhm
Q Factor 16
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 16
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 6GHz
Max DC Current 700mA
Test Frequency 250MHz
Inductance 1.6 nH
Current Rating 700mA
Construction Open Core
Depth 1.14mm
Number of Functions 1
Shielding Unshielded
Packing Method TR, 7 Inch
HTS Code 8504.50.80.00
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 10%
Packaging Tape & Reel
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Weight 2.012816mg
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 0603
Mount Surface Mount
