0603R-10NK

API Delevan
RoHS
/
Package 0603
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED (Type) Inductor 125C 4.8GHz 130mOhm 10nH
PDF
/
Inventory: 7783
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case 0603
Terminal Shape WRAPAROUND
Number of Pins 2
Weight 2.012816mg
Material - Core Ceramic
Shape/Size Description RECTANGULAR PACKAGE

Technical

Packaging Tape & Reel
Tolerance 10%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding Unshielded
Number of Functions 1
Depth 1.14mm
Construction Open Core
Current Rating 700mA
Inductance 10 nH
Test Frequency 250MHz
Max DC Current 700mA
Frequency - Self Resonant 4.8GHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 31
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 31
DC Resistance (DCR) - Parallel 130mOhm
Inductance-Nom (L) 0.01 μH

Dimensions

Height 1.02mm
Height Seated (Max) 1.016mm
Length 1.8034mm
Width 1.14mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
