0402R-9N0K
RoHS
/
Package SMD/SMT
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Fixed Inductors .009uH 10% .104ohm WW SMT 680mA
PDF
/
Inventory: 2834
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case SMD/SMT
Terminal Shape WRAPAROUND
Material - Core Ceramic
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Tape & Reel
Tolerance 10%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding Unshielded
Number of Functions 1
Depth 760μm
Construction Open Core
Current Rating 680mA
Case Code (Metric) 1005
Case Code (Imperial) 0402
Inductance 9 nH
Test Frequency 250MHz
Max DC Current 680mA
Frequency - Self Resonant 4.16GHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 22
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 22
DC Resistance (DCR) - Parallel 104mOhm
Inductance-Nom (L) 0.009 μH
Dimensions
Height 610μm
Height Seated (Max) 609.6μm
Length 1.27mm
Width 762μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
