SH50T-0.9-267

Amgis, LLC
RoHS
RoHS RoHS compliant
Package Radial, Horizontal - Corner Terminals
Category Inductors, Coils, Chokes / Fixed Inductors
Description FIXED IND 267UH 900MA 180 MOHM
PDF
/
Inventory: 2236
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 17.018mm
Length 17.526mm
Height Seated (Max) 0.492 12.50mm
Height 12.446mm

Technical

Inductance Frequency - Test 10kHz
DC Resistance (DCR) 180mOhm Max
Test Frequency 10kHz
Inductance 267μH
Current Rating 900mA
Shielding Unshielded
Current Rating (Amps) 900mA
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Toroidal
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.689Lx0.669W 17.50mmx17.00mm
Series SH50
Packaging Tray
Operating Temperature -40°C~125°C

Physical

Material - Core Iron Powder
Package / Case Radial, Horizontal - Corner Terminals
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 18 Weeks
