SH50S-3.0-47
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 47UH 3A 50 MOHM SMD
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Iron Powder
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series SH50
Size / Dimension 0.701Lx0.669W 17.80mmx17.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Type Toroidal
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 3A
Shielding Unshielded
Current Rating 3A
Inductance 47μH
Test Frequency 10kHz
DC Resistance (DCR) 50mOhm Max
Inductance Frequency - Test 10kHz
Dimensions
Height Seated (Max) 0.451 11.45mm
Length 17.8054mm
Width 16.9926mm
Compliance
RoHS Status ROHS3 Compliant
