SH50B-0.62-1500
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical, 4 Leads (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 1.5MH 620MA 1 OHM TH
PDF
/
Inventory: 3745
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 20.32mm
Length 36.83mm
Height Seated (Max) 1.378 35.00mm
Height 35.052mm
Technical
Inductance Frequency - Test 10kHz
DC Resistance (DCR) 1Ohm Max
Test Frequency 10kHz
Inductance 1.5mH
Current Rating 620mA
Shielding Unshielded
Current Rating (Amps) 620mA
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Toroidal
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 1.449Lx0.799W 36.80mmx20.30mm
Series SH50
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Material - Core Iron Powder
Package / Case Radial, Vertical, 4 Leads (Open)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
