SH260C-5.0-10

Amgis, LLC
RoHS
RoHS RoHS compliant
Package Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Toroidal Active Tray Fixed Inductor -40C~125C 10kHz 25mOhm 10muH
PDF
/
Inventory: 3885
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 18 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical (Open)
Material - Core Iron Powder

Technical

Operating Temperature -40°C~125°C
Packaging Tray
Series SH260
Size / Dimension 0.650Lx0.449W 16.50mmx11.40mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Toroidal
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 5A
Shielding Unshielded
Current Rating 5A
Inductance 10μH
Test Frequency 10kHz
DC Resistance (DCR) 25mOhm
Inductance Frequency - Test 10kHz

Dimensions

Height 19.304mm
Height Seated (Max) 0.760 19.30mm
Length 16.51mm
Width 11.4046mm

Compliance

RoHS Status ROHS3 Compliant
