SH150T-2.74-24
RoHS
RoHS compliant
RoHS compliantPackage Radial, Horizontal - Corner Terminals
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Toroidal Active Tray Fixed Inductor -40C~125C 10kHz 70mOhm 24muH
PDF
/
Inventory: 7354
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Horizontal - Corner Terminals
Material - Core Iron Powder
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series SH150
Size / Dimension 0.614Lx0.591W 15.60mmx15.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Toroidal
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 2.74A
Shielding Unshielded
Current Rating 2.74A
Inductance 24μH
Test Frequency 10kHz
DC Resistance (DCR) 70mOhm
Inductance Frequency - Test 10kHz
Dimensions
Height Seated (Max) 0.358 9.10mm
Length 15.5956mm
Width 15.0114mm
Compliance
RoHS Status ROHS3 Compliant
