AIRD-03-2R2M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
AIRD-03 Radial Vertical Cylinder 1.102Dia 28.00mm 2.2muH
PDF
/
Buying Options
Total Price: USD $4.49
Unit Price: USD $4.488748
≥1 USD $4.488748
≥10 USD $4.234661
≥100 USD $3.994966
≥500 USD $3.768832
≥1000 USD $3.55551
Inventory: 1765
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Material - Core Ferrite
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2011
Series AIRD-03
Size / Dimension 1.102Dia 28.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Current Rating 21A
Lead Pitch 22mm
Inductance 2.2μH
Test Frequency 1Hz
DC Resistance (DCR) 3mOhm Max
Max DC Current 90A
Inductor Application POWER INDUCTOR
Lead/Base Style Radial
Dimensions
Diameter 28mm
Height 21.0058mm
Height Seated (Max) 0.827 21.00mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
