AIRD-01-331K

Abracon LLC
RoHS
RoHS RoHS compliant
Package Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description AIRD-01 Radial Vertical Cylinder 0.650Dia 16.50mm 330muH
PDF
/
Buying Options
Total Price: USD $1.86
Unit Price: USD $1.8568
≥1 USD $1.8568
≥10 USD $1.57696
≥100 USD $1.45376
≥500 USD $1.29888
≥1000 USD $1.089
Inventory: 973
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 21mm
Height Seated (Max) 0.827 21.00mm
Height 20.955mm

Technical

Current - Saturation 3.8A
Inductance Frequency - Test 1kHz
Lead/Base Style Radial
Max DC Current 3.8A
DC Resistance (DCR) 336mOhm Max
Test Frequency 1kHz
Inductance 330μH
Lead Pitch 14.5mm
Current Rating 1.3A
Shielding Unshielded
Current Rating (Amps) 1.3A
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Type Wirewound
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.650Dia 16.50mm
Series AIRD-01
Published 2004
Packaging Bulk
Operating Temperature -25°C~85°C

Physical

Material - Core Ferrite
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 9 Weeks
