ECQ-E4103JF9
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Capacitors / Film Capacitors
Description
Radial FILM CAPACITOR ECQ-E(F) 400V 10000pF ±5% 0.406Lx0.169W 10.30mmx4.30mm
PDF
/
Inventory: 6710
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Terminal Shape WIRE
Dielectric Material Polyester, Metallized
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2005
Series ECQ-E(F)
Size / Dimension 0.406Lx0.169W 10.30mmx4.30mm
Tolerance ±5%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination PC Pins
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications General Purpose
HTS Code 8532.25.00.70
Capacitance 10000pF
Voltage - Rated DC 400V
Packing Method TR
Lead Pitch 5mm
Capacitor Type FILM CAPACITOR
Dielectric PET
Lead Spacing 0.197 5.00mm
Size Code 4117
Dimensions
Height Seated (Max) 0.488 12.40mm
Length 10.3mm
Width 4.3mm
Compliance
RoHS Status ROHS3 Compliant
