HFBR-1712TZ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Fiber Optics - Transmitters - Discrete
Description
TX Optical Fiber 160MBd 8-Pin DIP With Connector
PDF
/
Inventory: 9074
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Body Height 10.2mm
Technical
Transmission Type DIGITAL
Spectral Bandwidth 0.85nm
Optical Power Output-Nom 0.141mW
Emitter/Detector Type VCSE LASER DIODE
Operating Wavelength-Nom 850 nm
Fiber Optic Device Type TRANSMITTER
Fiber Type 50/125, 62.5/125, HCS, MMF
Current - DC Forward (If) (Max) 20mA
Wavelength 850nm
Voltage - DC Reverse (Vr) (Max) 2V
Data Rate 160 Mbps
Voltage - Forward (Vf) (Typ) 2.3V
Supply Voltage-Max (Vsup) 2.3V
Operating Temperature (Min) -20°C
Body Breadth 12.7 mm
Operating Temperature (Max) 75°C
Body Length or Diameter 12.7mm
Reach Compliance Code compliant
HTS Code 8517.62.00.50
Additional Feature OPTICAL OUTPUT POWER FOR 62.5/125 AND HCS FIBER TYPE: 0.251MW AND 0.398MW
Terminal Finish Tin (Sn)
Connector Type ST
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2012
Physical
Mounting Feature THROUGH HOLE MOUNT
Surface Mount NO
