AFCT-5943GZ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Fiber Optics - Transceiver Modules
Description
METRAK LASER DIODE PIN PHOTODIODE Through Hole General Purpose Transceiver Module 3.3V 0.251mW 2.7Gbps 70C
PDF
/
Inventory: 4380
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Surface Mount NO
Mounting Feature BOARD/PANEL MOUNT
Technical
Published 2007
Series METRAK
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code 5A991.B.5.A
Connector Type LC Duplex
Applications General Purpose
Additional Feature 2 X 5 ARRAY
HTS Code 8517.62.00.50
Subcategory Fiber Optic Transceivers
Voltage - Supply 3.1V~3.5V
Supply Voltage 3.3V
Reach Compliance Code compliant
Body Length or Diameter 48.46mm
Operating Temperature (Max) 70°C
Body Breadth 14.8 mm
Data Rate 2.7Gbps
Wavelength 1300nm
Fiber Type 9/125, SMF
Fiber Optic Device Type TRANSCEIVER
Built-in Feature AMPLIFIER
Operating Wavelength-Nom 1310 nm
Emitter/Detector Type LASER DIODE, PIN PHOTODIODE
Optical Power Output-Nom 0.251mW
Return Loss-Min 27 dB
Communication Standard GR-253, ITU-T-G.957, OC-48, SDH, SONET, STM-16
Dimensions
Body Height 10.6mm
Compliance
RoHS Status RoHS Compliant
