AFCT-5941ATGZ
RoHS
/
Package /
Category Optoelectronics / Fiber Optics - Transceiver Modules
Description
Infrared Transceivers Transceiver
PDF
/
Inventory: 9210
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Communication Standard ITU-T G.957, OC-48, SDH, SONET, STM-16
Operating Wavelength-Max 1360 nm
Operating Wavelength-Min 1260 nm
Connection Type LC CONNECTOR
Optical Power Output-Nom 0.562mW
Emitter/Detector Type LASER DIODE, MONITOR PHOTODIODE
Operating Wavelength-Nom 1300 nm
Built-in Feature AMPLIFIER
Fiber Optic Device Type TRANSCEIVER
Fiber Type 9/125, SMF
Supply Voltage-Min (Vsup) 3.1V
Supply Voltage-Max (Vsup) 3.5V
Body Breadth 13.4 mm
Supply Voltage 3.3V
Additional Feature IT ALSO HAS WAVELENGTH 1260 TO 1570 NM AND DETECTOR TYPE-PIN PHOTODIODE
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Published 2011
Dimensions
Body Height 9.63mm
Physical
Mounting Feature PANEL MOUNT, THROUGH HOLE MOUNT
Surface Mount NO
