AFBR-5905Z
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Optoelectronics / Fiber Optics - Transceiver Modules
Description
AVAGO TECHNOLOGIES AFBR-5905Z TRANSCEIVER, ATM, 2KM, MT-RJ, SFF
PDF
/
Inventory: 2978
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Body Height 9.8mm
Width 13.59mm
Technical
Communication Standard ATM, OC-3, SDH, SONET, STM-1
Optical Power Output-Nom 0.009mW
Emitter/Detector Type LASER DIODE, PIN PHOTODIODE
Operating Wavelength-Nom 1308 nm
Built-in Feature AMPLIFIER
Fiber Optic Device Type TRANSCEIVER
Fiber Type 50/125, MMF
Wavelength 1300nm
Data Rate 100 Mbps
Output Current 50mA
Row Spacing 10.16 mm
Supply Voltage-Max (Vsup) 3.465V
Operating Supply Voltage 3.3V
Max Output Current 50mA
Lead Pitch 1.778mm
Body Length or Diameter 49.56mm
Supply Voltage 3.3V
Subcategory Fiber Optic Transceivers
HTS Code 8517.62.00.50
Additional Feature 2 X 5 ARRAY, OPTICAL OUTPUT POWER FOR 62.5/125 FIBER TYPE: 0.026MW
Applications General Purpose
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin (Sn)
Connector Type MTRJ
ECCN Code 5A991.B.5.A
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Physical
Number of Pins 10
Package / Case Module
Mounting Type Through Hole
Mount Panel, Through Hole
Supply Chain
Factory Lead Time 16 Weeks
